Brass Shims
Brass shims are thin spacers cut from brass, a copper–zinc alloy, used to fill gaps, align parts and set exact clearances in machinery and assemblies. Brass resists corrosion, is non-magnetic, is easy to cut and form, and conducts heat and electricity well, so brass shims are widely used in automotive, aerospace, electrical and general engineering. We stock brass shim stock from 0.010mm to 1.000mm thick and can laser cut brass shims to your drawing.
Because brass is softer than steel, it suits light to moderate loads and fine adjustment. For higher loads or temperatures, consider stainless steel shims or steel shims, and for electrical conductivity see our copper shims.
Order your Brass Shims
You can order just a metre length of brass shim stock, ideal for R&D, with next-working-day delivery if your company is in Europe. We deliver within 2–3 working days anywhere else in the world. We also laser cut brass shims to your drawings and offer a rapid quotation and manufacturing service.
Brass Shim Washers
We supply shim washers laser cut to your specification, in more than 60 thicknesses starting from 0.01mm (0.0004″), including brass.
For Stainless Steel Stock ListIf you can’t see what you’re looking for call +44 (0)1952 299333 or email sales@hollinbrow.co.uk or leave a message below.
Brass Shim Stock Thickness Range
Brass
0.010mm x 150mm x 5m
0.020mm x 150mm x 5m
0.025mm x 150mm x 5m
0.030mm x 150mm x 5m
0.040mm x 150mm x 5m
0.050mm x 150mm x 5m
0.050mm x 300mm x 1m
0.075mm x 150mm x 5m
0.100mm x 150mm x 5m
0.100mm x 300mm x 1m
0.127mm x 150mm x 5m
0.150mm x 150mm x 5m
0.150mm x 300mm x 5m
0.200mm x 150mm x 5m
0.200mm x 300mm x 1m
0.300mm x 300mm x 1m
0.400mm x 300mm x 1m
0.500mm x 300mm x 1m
0.600mm x 300mm x 1m
0.700mm x 300mm x 1m
0.800mm x 300mm x 1m
0.900mm x 300mm x 1m
1.000mm x 300mm x 1m
Remember we can also supply thicker sheets and plates
Stainless Steel
0.005mm
0.008mm
0.010mm
0.0127mm
0.0150mm
0.020mm
0.025mm
0.030mm
0.035mm
0.040mm
0.045mm
0.050mm
0.055mm
0.060mm
0.070mm
0.075mm
0.080mm
0.090mm
0.100mm
0.120mm
0.127mm
0.130mm
0.140mm
0.150mm
0.160mm
0.170mm
0.180mm
0.190mm
0.200mm
0.210mm
0.220mm
0.230mm
0.240mm
0.250mm
0.260mm
0.270mm
0.280mm
0.290mm
0.300mm
0.350mm
0.381mm
0.400mm
0.450mm
0.500mm
0.550mm
0.600mm
0.635mm
0.650mm
0.700mm
0.750mm
0.800mm
0.850mm
0.900mm
0.950mm
1.000mm
1.100mm
1.200mm
1.300mm
1.400mm
1.500mm
1.600mm
1.700mm
1.800mm
1.900mm
2.000mm
2.500mm
3.000mm
Steel
0.025mm
0.050mm
0.075mm
0.100mm
0.127mm
0.150mm
0.200mm
0.250mm
0.300mm
0.381mm
0.400mm
0.500mm
0.600mm
0.635mm
0.650mm
0.700mm
0.800mm
0.900mm
1.000mm
1.200mm
1.500mm
2.000mm
2.500mm
3.000mm
4.000mm
5.000mm
6.000mm
8.000mm
10.000mm
Rememer we can lap your parts to the thickness you requireAluminium
0.025mm x 150mm x 5m
0.025mm x 500mm x 1m
0.030mm x 500mm x 100m
0.040mm x 100mm x 25m
0.050mm x 500mm x 1m
0.050mm x 500mm x 25m
0.050mm x 1000mm x 25m
0.100mm x 150mm x 5m
0.100mm x 300mm x 1m
0.100mm x 500mm x 25m
0.100mm x 1000mm x 25m
0.150mm x 500mm x 1m
0.150mm x 500mm x 25m
0.150mm x 1000mm x 25m
0.200mm x 500mm x 25m
0.200mm x 500mm x 100m
0.200mm x 1000mm x 25m
0.250mm x 610mm x 1m
0.300mm x 300mm x 1m
This is a list of stock gauges - if you can't see what your looking for give us a callCOPPER
0.010mm
0.020mm
0.030mm
0.040mm
0.050mm
0.060mm
0.100mm
0.150mm
0.200mm
0.250mm
0.300mm
0.400mm
0.500mm
Other thicknesses availableNICKEL
0.010mm
0.020mm
0.025mm
0.050mm
0.100mm
0.200mm
0.300mm
Phosphor Bronze
0.050mm
0.100mm
0.150mm
0.200mm
0.250mm
0.300mm
0.500mm
0.800mm
0.900mm
1.000mm
1.500mm
1.600mm
We can lapp, turn, mill and laser cut your partsOther Shim Materials
Need a different metal? See our stainless steel shims (stock list PDF), steel shims, aluminium shims, copper shims, nickel shims and plastic shims, or return to all metal shims.
Frequently Asked Questions About Brass Shims
What thicknesses of brass shim stock do you hold?
Brass shim stock is held from 0.010mm to 1.000mm; thicker brass sheets and plates are available on request.
Can brass shims be laser cut to my drawing?
Yes. Send us your drawing and we will quote for laser cut brass shims, with emergency same-day, next-day or 48-hour delivery if needed.
